4.3inch Car Rear Viewmirror Dual Display Rearview mirror,HK-04343LA
  • 4.3inch Car Rear Viewmirror Dual Display Rearview mirror,HK-04343LA
  • 4.3inch Car Rear Viewmirror Dual Display Rearview mirror,HK-04343LA
  • 4.3inch Car Rear Viewmirror Dual Display Rearview mirror,HK-04343LA
  • 4.3inch Car Rear Viewmirror Dual Display Rearview mirror,HK-04343LA

4.3inch Car Rear Viewmirror Dual Display Rearview mirror,HK-04343LA

>Screen Size: 4.3inch
>Display Screen: TFT-LCD
>Aspect Resolution: 480(H)*272(V)
>Working Voltage: 10V~30V
>Working Temperature: -20℃~+75℃
>Four ways Video input
>Signal System: PAL/Auto/NSTC
>Adjustable guide line (option)

Product Info





The video input of Left Video1 and Right Video1 are controled by CTR1.
When CTR1 is connected DC 12~24V,then no matter what state the left and right screen of the mirror are, it will be switched to the Left Video1 and Right Video1 video screen display.It recommended that CTR1 is connected to the reversing light.

The video input of Left Video2 and Right Video2 are controled by CTR2.
But it’s  priority is inferior than CTR1,when CTR1 and CTR2 connect power at the same time,then the rearview mirror screen will display two-video(Left Video1、RightVideo1) controled by CTR1 only。Only when CTR2 connected power,if the screen is off,then it will keep off on.If the screen is on,the left and right screen of rearview mirror will switch to Left Video2 and Right Video2.

How to display the rearview mirror screen.
